High-Precision Magnetic Linear Encoder - Anti-Seismic & Convenient for Wood Cutting, Grinding, and Stone Cutting Machines | Perfect for CNC Milling, DIY Woodworking, and Industrial Fabrication

Feature:1. It has strong anti‑seismic, oil proof, dust proof, waterproof, high temperature resistance and other properties.2. Small appearance designs, convenient installation, saving installation space, linear length reaches more than 100 meters.3. Suitable for milling machine, grinding machine, stone cutting machine, wood cutting machine and other occasion.4. Aluminum alloy material manufacturing ensuring maximum durability.5. Long line drive: Low (load current: below 20mA, residual voltage: below 0.4V); HIGH (load current: below 20mA, residual voltage: above 2.5V).Specification:Condition: 100% Brand NewItem Type: Magnetic LinearMaterial: Aluminum Alloy Model: MSR500Output VoltageLoad Current: Less than 10mAResidual Voltage: Less than 0.4VLong line drive: Low (load current: below 20mA, residual voltage: below 0.4V)HIGH (load current: below 20mA, residual voltage: above 2.5V)Response time: Voltage Output: Below 1US (cable length: 1m, absorption current: below 20mA)Long Line Drive: Below 1US(cable length: 1m, absorption current: below 20mA)Output Phase Difference: Phase difference between A and B: T/4±7/8 (1 period of A phase is T)Response Frequency: Maximum.500KHZReading Head Clearance: Maximum.2mm, 1mm-1.5mm is recommendedConsumption Current: below 70mA (no load)Input Voltage: DC5VLength: Approx. 3meter / 9.8ftResolution: 5μmCorresponding Magnetic Distance: 50:5mmInsulation Resistance: More than 20 m ΩVoltage Resistance: 500VAC (50/60Hz, time: 1 minute, between terminal and housing)Ambient Temperature: -10-70℃ (no condensation state), storage: -25-85℃ (no freezing)Protection Class: IP67 (IEC specification)Forward Vibration: 50m/ S2, 10-200 Hz X, Y and Z directions for 2 hours eachPackage List:1 x Magnetic Linear
